Infineon IGBT Modules 1200V 450A 3-PHASE FS450R12KE3 New in stock
Infineon FS450R12KE3, EconoPACK+ , N-Channel Isolated IGBT Module, 600 A max, 1200 V, Screw Mount
IGBT Modules, Infineon
The Infineon range of IGBT Modules offer low switching loss for switching up to 60 Khz frequencies.
The IGBTs span over a range of power modules like the ECONOPACK packages with collector emitter voltage at 1200V, PrimePACK IGBT half-bridge chopper modules with NTC up to 1600/1700V. The PrimePACK IGBT’s can be found in Industrial, commercial, construction and agricultural vehicles. The N-Channel TRENCHSTOP TM and Fieldstop IGBT Modules are suitable for hard switching and soft switching applications such as Inverters, UPS and Industrial drives.
Package styles include: 62mm Modules, EasyPACK, EconoPACKTM2/EconoPACKTM3/EconoPACKTM4
IGBT Discretes & Modules, Infineon
The Insulated Gate Bipolar Transistor or IGBT is a three-terminal power semiconductor device, noted for high efficiency and fast switching. The IGBT combines the simple gate-drive characteristics of the MOSFETs with the high-current and low–saturation-voltage capability of bipolar transistors by combining an isolated gate FET for the control input, and a bipolar power transistor as a switch, in a single device.
Diagrams
Specifications
Product Attribute Attribute Value
Manufacturer: Infineon
Product Category: IGBT Modules
RoHS: N
Product: IGBT Silicon Modules
Configuration: Hex
Collector- Emitter Voltage VCEO Max: 1200 V
Collector-Emitter Saturation Voltage: 2.15 V
Continuous Collector Current at 25 C: 600 A
Gate-Emitter Leakage Current: 400 nA
Pd - Power Dissipation: 2.1 kW
Package / Case: EconoPACK+
Minimum Operating Temperature: - 40 C
Maximum Operating Temperature: + 125 C
Packaging: Tray
Height: 17 mm
Length: 162 mm
Width: 150 mm
Brand: Infineon Technologies
Mounting Style: Chassis Mount
Maximum Gate Emitter Voltage: 20 V
Product Type: IGBT Modules
Factory Pack Quantity: 4
Unit Weight: 2.006 lbs
